5.2 Basic System Construction — KX-TDA30
240 Installation Manual
*1 In addition to the supplied AC adaptor, an additional AC adaptor can be connected to the Hybrid IP-
PBX.
*2 The Hybrid IP-PBX has 4 Super Hybrid Ports pre-installed.
SLT Wireless Phone Fax Machine
PCKX-T7636/KX-T7633 DSS
Console
Doorphone & Door Opener
AC Cord & AC Adaptor
*
1
Private
IP Network
Station Message
Detail Recording (SMDR)
PC
Router
ISDN BRI Line
ISDN BRI Line
(Digital Trunk)
(Digital Trunk)
ISDN BRI Line
(Digital Trunk)
DLC8
(KX-TDA3172)
DLC4
(KX-TDA3171)
SLC8
(KX-TDA3174)
SLC4
(KX-TDA3173)
DPH4
(KX-TDA3161)
DPH2
(KX-TDA3162)
ECHO8
(KX-TDA3166)
EXT-CID
(KX-TDA3168)
MEC
(KX-TDA3105)
MSG2
(KX-TDA3191)
IP-GW4
(KX-TDA3480)
DID4
(KX-TDA3182)
LCOT2
(KX-TDA3183)
BRI2
(KX-TDA3280)
BRI1
(KX-TDA3283)
Telephone
Company
SLT Wireless Phone Fax Machine
Hybrid IP-PBX
DPT
APT DPT DSS Console
Voice
Processing
System
Voice
Processing
System
Radio
Amplifier Pager/Speaker
Server PC
CID4
(KX-TDA3193)
PT-interface CS PS
4 Super Hybrid Ports
*
2
PT-interface CS PS
Batteries
Main Board
RMT
(KX-TDA3196)
KX-T7600 DPT KX-T7600 DPT
Analogue
Trunk
LCOT4
(KX-TDA3180)
