Panasonic KX-TDA30

2.2 Installation of the Hybrid IP-PBX — KX-TDA100/KX-TDA200
Installation Manual 41
Closing the Front Cover
1. Hook the front cover onto the cabinet (line up the protrusions on the cover with the
receptacles on the cabinet). Then slide the front cover to the left until it locks.
2. Turn the screw clockwise to tighten.
3. Secure the screw cover.
Notes
• For safety reasons, close the front cover and tighten the screw when the Hybrid IP-
PBX is in operation.
• Do not forget to tighten the screw before securing the screw cover.
1
2
