2.2 Installation of the Hybrid IP-PBX — KX-TDA100/KX-TDA200
Installation Manual 45
2. Turn the 4 screws anticlockwise to loosen them.
3. Pull the release lever in the direction of the arrow to disconnect the PSU from the back
board.
4. Replace the PSU.
5. Follow the steps in "Installing the Power Supply Unit".
Screws
Release Lever
Back Board
Current PSU
New PSU
