Panasonic KX-TDA30

2.4 Installation of the Trunk Cards — KX-TDA100/KX-TDA200
Installation Manual 93
Switch Settings
Pin Assignments
RJ45 Connector for Trunk Use
RJ45 Connector for Extension Use
BNC (coaxial) Connector (TX)
Switch Type Usage and Status Definition
Termination Slide
Select 120 (default) or 75 for connector type to be
used.
A/B Slide When using an RJ45 connector, select A (default) for trunk
or B for extension use.
When using BNC connectors, keep the A position.
No. Signal Name Level [V] Function
1 RX+ (+) Receive data (+)
2 RX- (-) Receive data (-)
3 Reserved ––
4 TX- (-) Transmit data (-)
5 TX+ (+) Transmit data (+)
6-8 Reserved ––
No. Signal Name Level [V] Function
1 TX- (-) Transmit data (-)
2 TX+ (+) Transmit data (+)
3 Reserved ––
4 RX+ (+) Receive data (+)
5 RX- (-) Receive data (-)
6-8 Reserved ––
No. Signal Name Level [V] Function
1 TX+ (+) Transmit data (+)
2 TX- (-) Transmit data (-)
8
1
8
1
1
2
