Panasonic Lumix S5

1. Introduction
29
5
2
3
9
12
13
4
1
7
6
8
11
10
1 Eye cup (l 518)
2 Viewfinder (l 32, 66, 493)
3
Eye sensor (l 66)
4
Tripod mount (l 523)
0 If you attempt to attach a tripod
with a screw length of 5.5 mm
(0.22 inches) or more, you may
not be able to securely fix it in
place or it may damage the
camera.
5
Battery grip connector (cover for
the battery grip connector)
(l 490)
0 Keep the cover for the battery
grip connector out of reach of
children to prevent swallowing.
6 [REMOTE] socket (l 491)
7 Card slot 1 (l 46)
8
Card slot 2 (l 46)
9
Card door (l 46)
10
Card access light (l 46)
11
DC coupler cover (l 492)
0 When using an AC adaptor,
ensure that the Panasonic DC
Coupler (DMW-DCC17:
optional) and AC Adaptor
(DMW-AC10: optional) are
used.
12 Battery door (l 37)
13 Battery door release lever (l 37)
