14. Menu Guide
376
[Custom] menu ¨ [Focus/Shutter]
[AF-Point Scope
Setting]
[Keep Enlarged
Display]
[ON]/`[OFF]
[PIP Display] [FULL]/`[PIP]
Changes the enlarged screen settings of AF-Point Scope
(l 97).
[Keep Enlarged Display]: Setting this to [ON] maintains the
enlarged screen after pressing the Fn button until it is
pressed again.
[PIP Display]: Sets the display method (full screen mode/
windowed mode) of the enlarged screen.
[Shutter AF]
`[ON]/[OFF]
This adjusts focus automatically when you press the shutter
button halfway.
[Half-Press Shutter]
[ON]/`[OFF]
You can release the shutter quickly by pressing the shutter
button halfway.
[Quick AF]
[ON]/`[OFF]
When the amount of camera shake becomes small, the
camera will automatically adjust the focus and focus
adjustment will then be quicker when the shutter button is
pressed.
0
The battery will drain faster than usual.
0
This function is not available in the following cases:
In preview mode
In low light situations
[Eye Sensor AF]
[ON]/`[OFF]
When looking through the viewfinder, if the eye sensor
operates, then AF will function.
0
[Eye Sensor AF] may not work in low light situations.
