Panasonic Lumix S5 User Manual

14. Menu Guide
377
[Custom] menu ¨ [Focus/Shutter]
[Looped Focus
Frame]
[ON]/`[OFF]
When moving the AF area or MF Assist, this enables its
position to loop from one edge to the other edge of the
screen.
[AFC Start Point
(225-Area)]
[ON]/`[OFF]
When the focus mode is set to [AFC] in the [ ] AF mode,
you can specify which area to start [AFC].
0 For details, refer to page 107.
[Custom] menu ¨ [Operation]
[Q.MENU Settings]
[Layout Style] `[MODE1]/[MODE2]
[Front Dial
Assignment]
[Item]/`[Value]
[Item Customize (Photo)]
[Item Customize (Video)]
Customizes the Quick menu.
0 For details, refer to page 332.
[Touch Settings]
[Touch Screen] `[ON]/[OFF]
[Touch Tab] [ON]/`[OFF]
[Touch AF] `[AF]/[AF+AE]
[Touch Pad AF] [EXACT]/[OFFSET1] to [OFFSET7]/
`[OFF]
Enables touch operation on the monitor display.
[Touch Screen]: All touch operations.
[Touch Tab]: Operations of tabs, such as [ ] on the right
side of the screen.
[Touch AF]: Operation to optimize the focus ([AF]) for a
touched subject. Alternatively, operation to optimize both the
focus and brightness ([AF+AE]). (l 116)
[Touch Pad AF]: Touch pad operation during viewfinder
display. (l 118)

Panasonic Lumix S5 Specifications

General

Style	Digital Single Lens Mirrorless
Color	Black
Image Sensor	35mm full-frame (35.6mm x 23.8mm) CMOS sensor
Crop Factor	1.0
Total Pixels	25.28 megapixels
Approx. 8.29 megapixels (3840 x 2160)	Approx. 30.4 megapixels
Image Processor	-
Lens Mount	L-Mount
Image Stabilization	Image sensor shift type (5-axis / 5.0-stop)
Dual I.S. (6.5-stop Dual I.S. 2 compatible)	-
Focusing	AFS (Single) / AFC (Continuous) / MF
Viewfinder Type	OLED Live View Finder
Shooting Modes	Landscape
Picture Styles: Auto	Fine Detail
Continuous Shooting	-
With Servo AF: Approx. 4 shots/sec	Up to 14fps with AF tracking UHS-II card support
Exposure Compensation	1/3 EV step ±5EV (±3EV for motion picture)
Automatic Exposure Bracketing (AEB)	-
ISO Sensitivity	1-Stop Display: [100]
ISO can be expanded to L:50	Auto (100-25600)
Shutter Speed	30-1/8000 sec (1/2 or 1/3 stop increments)
White Balance	Shade
Type	Touch screen Vari angle Clear View II TFT
Size	Free-angle
MP4 H.264	recording level can be manually adjusted by user)
MP4: H.264/MPEG-4 AVC	recording level can be manually adjusted by user)
ALL-I (FHD 29.97/25.00	HD - MPEG4 AVC / H.264 variable (average) bit rate
MP4 Video: Full HD (16:9) 1920 x 1080 - MPEG4 AVC/H.264	MOV (Video: H.264 Intra frame / inter frame
Max Movie Size	1920 x 1080 (59.94
1920 x 1080 (59.94	23.976 fps) IPB (Standard
1920 x 1080 ( 29.97	24
Full HD (16:9) 1920 x 1080 (59.94	23.98 fps) intra or inter frame
HD - 1280 x 720 (119.9	1920 x 1080 (29.97
640 x 480 (29.97	1280 x 720 (HD)
MP4: 4096 x 2160: 150Mbps 428 Mins	29 min 59 sec
Max Image Size	(1:1) 4640x 4640
RAW: (RAW) 6240 x 4160	(M1) 4464x2976
4:3 ratio (L) 5952x4480	(S3) 720x480
16:9 ratio (L) 6720x3776	(S3) 720x408
1:1 ratio (L) 4480x4480	(S3) 480x480
(RAW) 6720x4480	(4:3) 5328 x 4000
JPEG 1:1: (L) 4000 x 4000	JPEG: (L) 5472x3648
RAW: (RAW) 5472x3648	(M) 3984 x 2656
JPEG 4:3: (L) 5328x4000
JPEG 16:9: (L) 6000x3368
JPEG 1:1: (L) 4000x4000
Wireless Connectivity	GPS
Interface Connectors	XLR 3-pin connector x2
Storage Type	SD/SDHC memory card
1x SD/SDHC/SDXC and UHS-I	SD
Compact Power Adapter CA-CP200L: 24V DC	16Wh)
Battery life	AE 50%
Approx. 860 (at 0°C	Approx. 1200 shots (at 23°C
Approx. 980 (at 0°C	AE 50%
Operating Environment	(85% relative humidity);
Approx. -5 to 45°C	0 C to 40 C
Body Materials	-
Water / Dust resistance	-

Weight and Dimensions

Depth	78.5 mm
Height	105.2 mm
Width	139 mm
Net Weight	714 g
