21.1.3.3. Power Supply P.C.B.
POWER SUPPLY
P.C.B
DC-DC CONVERTER
IC2903
DC-DC CONVERTER
IC2900
FUSE PROTECTOR
FP2901
CONNECTOR, CN2016
CONNECTOR, CN6001
CONNECTOR, CN2004
Fig. 4 Power Supply P.C.B.
145
SA-BT100P / SA-BT100PC
