24.1. Component Parts List
Ref.
No.
Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 J0KD00000126 FERRITE CORE [M]
2 L6FAJCCH0007 FAN MOTOR [M]
3 REX1286 4P FFC CABLE (BD DRIVE-MAIN) [M]
4 REX1287 11P WIRE (MAIN-SMPS) [M]
5 REXX0640-J BLACK WIRE (AC-SMPS) [M]
6 REXX0641-J RED WIRE (AC-SMPS) [M]
7 REXX0651 8P WIRE (SMPS-DAMP) [M]
9 REZ1863 40P FFC CABLE (DIGITAL-BD
DRIVE)
[M]
10 REZ1864 30P FFC CABLE (DIGITAL-MAIN) [M]
11 REZ1865 30P FFC CABLE (PAN-MAIN) [M]
12 REZ1866 24P FFC CABLE (DSP-MAIN) [M]
13 REZ1867 22P FFC CABLE (DIGITAL-MAIN) [M]
14 REZ1868-1 20P FFC CABLE (DSP-MAIN) [M]
15 REZ1869 19P FFC CABLE (WIRELESS-MAIN) [M]
16 REZ1871-1 17P FFC CABLE (D-AMP-MAIN) [M]
17 REZ1872-1 15P FFC CABLE (DSP-DIGITAL) [M]
18 REZ1873 14P FFC CABLE (POD-MAIN) [M]
19 REZ1874 13P FFC CABLE (SD-DIGITAL) [M]
20 REZ1877 4P WIRE (PAN-HP) [M]
21 REZ1878 5P WIRE (PAN-OPN) [M]
22 REZ1883 5P WIRE (OPN-PWRBTN) [M]
23 RYF0841-K CRADLE BASE UNIT [M]
24 RXQX0041 CUSHION ASSY [M]
25 RXXX0085-1J HEAT SINK UNIT [M]
26 RYP0840-K2 CRADLE PANEL UNIT [M]
27 RXQX0076 AC-IN SHIELD PLATE UNIT [M]
28 VXY2001-SER BD DRIVE UNIT [M]
29 RYF0839-K TRAY LID UNIT [M]
30 RYQ0681-K STAND UNIT [M]
31 RKAX0028-K LEG CUSHION [M]
33 RGR0382A-A2 REAR PANEL [M] P
33 RGR0382A-B2 REAR PANEL [M] PC
34 RHD30111-3 SCREW [M]
35 RHD30119-S SCREW [M]
36 RHD30156 SCREW [M]
37 RXXX0105 HEATSINK UNIT C [M]
38 RKM0592-K TOP CABINET [M]
39 RMA2106 MECHA ANGLE F [M]
40 RMA2110 MECHA ANGLE R [M]
41 RMA2113 B/E ANGLE [M]
42 RMA2114 SD ANGLE [M]
43 RMAX0118-1 PCB BRACKET [M]
44 RFKGABT100PK FRONT PANEL ASS´Y [M]
46 RMC0750 PANEL EARTH SPRING [M]
47 RMC0753 MECHA EARTH SPRING [M]
48 RMKX0127-K1 TRANSMITTER CHASSIS [M]
49 RMKX0144B-3 BOTTOM CHASSIS [M]
50 RMQX0233-K FAN COVER [M]
51 RMVX0117-K CONNECTOR COVER [M]
52 RSC0828-1 MECHA SHIELD PLATE [M]
53 RSC0841 PANEL SHIELD [M]
54 VHD1224-1 SCREW [M]
55 RGKX0329-Q VOLUME LIGHTING RING [M]
56 RGL0715-Q LIGHT GUIDE [M]
57 RGU2564-K POWER BUTTON [M]
58 RGU2565-K OPEN BUTTON [M]
59 RGU2566-K SELECTOR BUTTON [M]
60 RGU2567-K PLAY BUTTON [M]
61 RGWX0076-1KJ VOLUME KNOB [M]
62 RHD26016-1L SCREW [M]
63 RHD26046 SCREW [M]
64 RHD30007-K2J SCREW [M]
65 RHD30070 EARTH TERMINAL [M]
66 RMA2146 LID ANGLE [M]
67 RMB0892 SPRING [M]
Ref.
No.
Part No. Part Name & Description Remarks
68 RMC0465 TR SPRING [M]
69 RMC0749 HP EARTH SPRING [M]
70 RMC0751 SD EARTH SPRING [M]
71 RMCX0055 SPRING PLATE [M]
72 RMNX0149-1 FL HOLDER [M]
73 RMNX0253 LED HOLDER [M]
74 RMR1868-K SHAFT HOLDER [M]
75 RMZX0038 IC INSULATOR [M]
76 XSN3+4FJ SCREW [M]
77 XTB3+10JFJ SCREW [M]
78 XTW3+8TFJ SCREW [M]
80 RXXX0104 HEATSINK UNIT B [M]
81 RSC0824 RADIATION RUBBER [M]
PACKING MATERIALS
P1 RPG8453 PACKING CASE [M] P
P1 RPG8454 PACKING CASE [M] PC
P2 RPN2039 POLYFOAM [M]
P3 RPFX0058-1J MIRAMAT [M]
ACCESSORIES
A1 N2QAKB000061 REMOTE CONTROL [M]
A1-1 RKK-BT100P R/C BATTERY COVER [M]
A2 K2CB2CB00021 AC CORD [M]
A3 RQT9129-P O/I BOOK (En) [M]
A3 RQT9130-C O/I BOOK (Cf) [M] PC
A4 RSA0007-M FM INDOOR ANTENNA [M]
A5 K2KA2BA00001 VIDEO CABLE [M]
A6 N1DAAAA00002 AM LOOP ANTENNA [M]
PRINTED CIRCUIT BOARDS
PCB1 REP4369A DSP PCB [M]
(RTL)
PCB2 RFKB4368A DIGITAL PCB [M]
(RTL)
PCB3 RFKB4370A MAIN PCB [M]
(RTL)
PCB4 REP4371A PANEL PCB [M]
(RTL)
PCB5 REP4371A HEADPHONE P.C.B [M]
(RTL)
PCB6 REP4371A SD P.C.B [M]
(RTL)
PCB7 REP4371A OPEN/CLOSE P.C.B [M]
(RTL)
PCB8 REP4371A POWER BUTTON P.C.B [M]
(RTL)
PCB9 REP4371A WIRELESS ADAPTER P.C.B [M]
(RTL)
PCB10 REPX0621G D-AMP P.C.B [M]
(RTL)
PCB11 REPX0622V SMPS PCB [M]
(RTL)
PCB12 REPX0622V AC INLET P.C.B [M]
(RTL)
PCB13 REPX0631A-C I-POD CRADLE P.C.B [M]
(RTL)
INTEGRATED CIRCUITS
IC100 MN103SF73NXW IC MICRO-PROCESSOR [M]
IC101 C0JBAZ002843 IC 24BIT SERIAL PARALLEL
CONVERTER
[M]
IC102 C0EBE0000242 IC RESET [M]
IC103 RFKWEDF001PA IC EEPROM [M]
(RTL)
IC104 C0CBABC00117 IC VOLTAGE REGULATOR [M]
IC105 C3EBFC000042 IC EEPROM [M]
IC500 C1AB00002750 IC AUDIO INPUT SELECTOR [M]
154
SA-BT100P / SA-BT100PC
