Panasonic SA-BT100P - Page 155

Ref.
No.
Part No. Part Name & Description Remarks
IC501 C0ABBB000189 IC OP-AMP [M]
IC502 C0ABBB000189 IC OP-AMP [M]
IC503 C0ABBB000189 IC OP-AMP [M]
IC504 C0ABBB000189 IC OP-AMP [M]
IC505 C0ABBB000189 IC OP-AMP [M]
IC509 C0ABBB000125 IC OP-AMP [M]
IC801 C1AB00002822 IC HD/SD VIDEO DRIVER [M]
IC1001 C0DBZYE00002 IC USB HIGH SIDE SWITCH [M]
IC1101 C0ABAA000114 IC SIGNAL ISOLATION AMP [M]
IC1102 C0ABBB000189 IC OP-AMP [M]
IC1103 MFI341S2095 IC CO-PROCESSOR [M]
IC3001 C2HBZY000027 IC DSP [M]
IC3002 RFKWBT100DS1 IC FLASH ROM [M]
IC3003 C3ABMG000238 IC SDRAM [M]
IC3004 C3ABMG000238 IC SDRAM [M]
IC3101 C2HBZY000028 IC DSP [M]
IC3102 RFKWBT100DS2 IC FLASH ROM [M]
IC3103 C3ABMG000238 IC SDRAM [M]
IC3104 C3ABMG000238 IC SDRAM [M]
IC3201 C0FBAK000026 IC A/D CONVERTER [M]
IC3401 C0JBAB000661 IC INVERTER [M]
IC3402 C0JBAB000661 IC INVERTER [M]
IC3403 C0JBAR000434 IC MULTIPLEXER [M]
IC3404 C1BB00000692 IC DIR/DIT [M]
IC3501 C0FBBK000044 IC D/A CONVERTER [M]
IC3551 C0JBAZ002811 IC BUS BUFFFER [M]
IC3601 C0DBAKG00007 IC DC/DC CONVERTER [M]
IC3602 C0DBZYY00018 IC +3.3V REGULATOR [M]
IC5000 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5200 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5300 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5400 C1BA00000487 IC AUDIO DIGITAL POWER AMP [M]
IC5500 C0JBAB000902 IC INVERTER GATE [M]
IC5501 C0JBAF000716 IC D-TYPE FLIP-FLOP [M]
IC5701 C5HACYY00004 IC SWITCHING REGULATOR [M]
IC5799 MIP4110MSSCF IC SWITCHING REGULATOR [M]
IC5801 C0DABFC00002 IC SHUNT REGULATOR [M]
IC5899 C0DAEMZ00001 IC SHUNT REGULATOR [M]
IC6001 C0HBB0000057 IC FL DISPLAY DRIVER [M]
IC7001 C0DBAYY00333 IC SWITCHING REGULATOR
CONTROLLER
[M]
IC7002 C0DBZYY00018 IC +3.3V REGULATOR [M]
IC7003 C0DBZHG00047 IC +9V REGULATOR [M]
IC51001 MN2WS0043AP IC DV LSI [M]
IC51002 C0EBE0000368 IC RESET [M]
IC51003 C1CB00002777 IC CLOCK GENERATOR [M]
IC51005 C1CB00002408 IC CLOCK GENERATOR [M]
IC51302 C3FBSC000029 IC NAND FLASH ROM [M]
IC51303 C3ZBL0000027 IC EEPROM [M]
IC52001 C3ABSC000018 IC DDR2 SDRAM [M]
IC52002 C3ABSC000018 IC DDR2 SDRAM [M]
IC52003 C3ABSC000018 IC DDR2 SDRAM [M]
IC52006 C1CB00002678 IC ZERO DELAY BUFFER [M]
IC52010 C3ABSC000018 IC DDR2 SDRAM [M]
IC52240 C1CB00002678 IC ZERO DELAY BUFFER [M]
IC52271 C3ABSG000051 IC DDR2 SDRAM [M]
IC52272 C3ABSG000051 IC DDR2 SDRAM [M]
IC54028 C0FBBK000049 IC AUDIO D/A CONVERTER [M]
IC56002 MN864704AKP IC HDMI TRANSMITTER [M]
IC58001 C0DBAYY00317 IC STEPDOWN DC/DC CONVERTER [M]
IC58003 C0DBAYY00273 IC DC/DC CONVERTER [M]
IC58004 C0DBAYH00003 IC ONE CHANNEL DC/DC
CONVERTER
[M]
IC58301 C0CBCDD00004 IC HDMI +5V REGULATOR [M]
IC58303 C0DBEYY00016 IC HDMI +3.3V REGULATOR [M]
IC58304 C0DBGFD00024 IC HDMI +1.2V REGULATOR [M]
TRANSISTORS
Q101 B1ADCE000012 TRANSISTOR [M]
Q102 B1GFGCAA0001 TRANSISTOR [M]
Q500 B1ADCE000012 TRANSISTOR [M]
Q502 B1GFGCAA0001 TRANSISTOR [M]
Ref.
No.
Part No. Part Name & Description Remarks
Q503 B1GFGCAA0001 TRANSISTOR [M]
Q504 B1GFGCAA0001 TRANSISTOR [M]
Q506 B1GFGCAA0001 TRANSISTOR [M]
Q507 B1GFGCAA0001 TRANSISTOR [M]
Q508 B1GFGCAA0001 TRANSISTOR [M]
Q509 B1ADCE000012 TRANSISTOR [M]
Q510 B1GFGCAA0001 TRANSISTOR [M]
Q520 B1GFGCAA0001 TRANSISTOR [M]
Q1101 B1ABCF000176 TRANSISTOR [M]
Q1102 B1ADCE000012 TRANSISTOR [M]
Q1103 B1ADCE000012 TRANSISTOR [M]
Q3601 B1DHDD000029 TRANSISTOR [M]
Q5101 B1ABCF000176 TRANSISTOR [M]
Q5102 B1ABCF000176 TRANSISTOR [M]
Q5601 B1ABCF000176 TRANSISTOR [M]
Q5602 B1ABCF000176 TRANSISTOR [M]
Q5603 B1ADCE000012 TRANSISTOR [M]
Q5604 B1ABCF000176 TRANSISTOR [M]
Q5640 B1BACD000018 TRANSISTOR [M]
Q5641 2SC584500L TRANSISTOR [M]
Q5642 2SC584500L TRANSISTOR [M]
Q5644 2SC584500L TRANSISTOR [M]
Q5720 2SC3940ARA TRANSISTOR [M]
Q5721 2SA207700L TRANSISTOR [M]
Q5722 B1ABCF000176 TRANSISTOR [M]
Q5802 B1ABCF000176 TRANSISTOR [M]
Q5803 2SC3940ARA TRANSISTOR [M]
Q5860 2SA207700L TRANSISTOR [M]
Q5861 B1ABCF000176 TRANSISTOR [M]
Q5862 B1ABCF000176 TRANSISTOR [M]
Q5898 B1ABCF000176 TRANSISTOR [M]
Q6001 B1GBCFGN0018 TRANSISTOR [M]
Q6002 B1GBCFGN0018 TRANSISTOR [M]
Q6003 B1GBCFGN0018 TRANSISTOR [M]
Q6101 B1GBCFGN0018 TRANSISTOR [M]
Q7001 B1BABK000001 TRANSISTOR [M]
Q7002 B1CHPD000003 TRANSISTOR [M]
Q7003 B1CHPD000003 TRANSISTOR [M]
Q7004 2SB0621AHA TRANSISTOR [M]
Q7005 B1ADCE000012 TRANSISTOR [M]
Q7006 2SC3940ARA TRANSISTOR [M]
Q7007 B1ABCF000176 TRANSISTOR [M]
Q7008 B1ABCF000176 TRANSISTOR [M]
Q55015 2SA153200L TRANSISTOR [M]
Q55016 2SA153200L TRANSISTOR [M]
Q55017 2SA153200L TRANSISTOR [M]
Q55018 B1ADCF000154 TRANSISTOR [M]
Q55019 B1ADCF000154 TRANSISTOR [M]
Q56004 B1ABDF000026 TRANSISTOR [M]
Q56005 B1ABDF000026 TRANSISTOR [M]
Q56006 B1ABDF000026 TRANSISTOR [M]
Q56007 B1ABDF000026 TRANSISTOR [M]
Q56008 B1ABDF000026 TRANSISTOR [M]
Q58001 2SB1218A0L TRANSISTOR [M]
Q58002 B1CHQD000008 TRANSISTOR [M]
Q58004 B1MBDDA00015 TRANSISTOR [M]
Q58005 B1CFRD000023 TRANSISTOR [M]
QR101 B1GBCFLL0037 TRANSISTOR [M]
QR504 B1ADCE000012 TRANSISTOR [M]
QR801 B1GBCFLL0037 TRANSISTOR [M]
QR802 B1GBCFLL0037 TRANSISTOR [M]
QR803 B1GBCFLL0037 TRANSISTOR [M]
QR1101 B1GBCFJJ0051 TRANSISTOR [M]
QR1102 B1GBCFJJ0051 TRANSISTOR [M]
QR3401 B1GDCFJN0001 TRANSISTOR [M]
QR3601 B1GBCFJJ0001 TRANSISTOR [M]
QR5801 UNR221400L TRANSISTOR [M]
QR5810 B1GBCFLL0037 TRANSISTOR [M]
QR7001 B1GBCFGG0030 TRANSISTOR [M]
QR51001 B1GDCFGG0028 TRANSISTOR [M]
QR51002 B1GDCFGG0028 TRANSISTOR [M]
QR51003 B1GBCFGG0024 TRANSISTOR [M]
QR51004 B1GBCFGG0024 TRANSISTOR [M]
155
SA-BT100P / SA-BT100PC
