Panasonic SA-VK480EE - Mechanical Replacement Part List

150
52 REXX0690-1 5P WIRE (USB-DVD
MODULE)
1
55 REXX0683-1 8P WIRE (SMPS-
DAMP)
1
56 REEX0905 50P FFC (MAIN-
DVD MODULE)
1
57 REEX0987 8P FFC (MAIN-
DECK)
1
58 REEX0988 12P WIRE (MAIN-
DECK)
1
59 REXX0679-1 7P WIRE (PANEL-
MIC)
1
60 REXX0680 11P WIRE (MAIN-
SMPS)
1
61 REXX0681 2P WIRE (PANEL-
MUSIC PORT)
2
62 REXX0684-1 BLACK WIRE (AC
INLET-SMPS)
1
63 REXX0685-1 RED WIRE (AC
INLET-SMPS)
1
64 REXX1028 2P WIRE (MIC-AC
INLET)
1
65 RWJ0102050KR 2P WIRE (MOTOR) 1
66 RWJ1103055SS 3P WIRE (PANEL-
REMOTE)
1
67 RWJ1108055SS 8P WIRE (PANEL-
VOLUME)
1
68 J0KD00000126 FERRITE CORE 1
69 RKMX0144A-K TOP CABINET 1
70 RMKX0148-4 BOTTOM CHASSIS 1
71 RMKX0149-2 INNER CHASSIS 1
72 RMVX0126 HOLE COVER 2
73 RSCX0216 BACK END SHIELD
PLATE
1
74 RMQX0319-W VOLUME DIFFUSER 1
75 RSCX0194 CASSETTE SHIELD
PLATE
1
CASSETTE DECK
101 RED0064-2 R/P HEAD BLOCK
SUB ASSY
1
103 RFKJSTR280PP MAIN CHASSIS
ASS'Y
1
104 XYC2+JF17FJ PCB EARTH SCREW 1
105 RDK0026-4 MAIN GEAR 1
106 XTW26+10SFJ SUB-CHASSIS
SCREW
3
107 RDV0033-4 WINDING BELT 1
108 RDV0034-2 CAPSTAN BELT A 1
109 XTW2+5LFJ HEAD BLOCK UNIT
SCREW
2
110 RHD26022-1 MOTOR SCREW 2
111 REM0120 CAPSTAN MOTOR
ASS'Y
1
112 RXL0124 PINCH ROLLER F
ASSY
1
112-1 RMB0401 PINCH ARM SPRING
'F'
1
113 RXL0126 WINDING ARM ASSY 1
114 RMK0283A-2 SUB-CHASSIS 1
115 RMB0408 THRUST SPRING 1
116 RXQ0470-2 PLUNGER ASSY 1
116-1 RMS0398-1 MOVING CORE 1
117 RXF0061-1 FLYWHEEL F ASSY 1
118 RML0372-2 WINDING LEVER 1
119 RXL0125 PUNCH ROLLER R
ASS'Y
1
119-1 RMB0402 PUNCH ARM SPRING
R
1
120 RXF0062-1 FLYWHEEL R ASS'Y 1
TRAVERSE DECK
340 RD-DDTX004-V TRAVERSE ASS'Y 1 (RTL)
PACKING MATERI-
ALS
P1 RPGX2202 PACKING CASE 1
P2 RPNX0640 POLYFOAM 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
P3 RPFX0198 MIRAMAT SHEET 1
ACCESSORIES
A1 N2QAYB000423 REMOTE CONTROL 1
A1-1 RKK-PT470EBK R/C BATTERY
COVER
1
A2 K2CQ2CA00007 AC CORD 1
A3 RQTX0280-R O/I BOOK (Ru/Ur) 1
A4 RSAX0002 FM INDOOR
ANTENNA
1
A5 N1DYYYY00003 AM LOOP ANTENNA 1
A6 K2KA2CA00011 VIDEO CABLE 1
A7 RP-VK21E-K MIC 1
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
