3. Design and Function
This chapter contains information on the design of the device and the
functions provided.
The connection ports, pin assignments and interfaces available on the
device are described.
INFORMATION
Information on the input modules is provided in Chapter ""Input Mod-
ules" on Page164.
156
The Parker Service Master CONNECT V1.0/04/20
Design and Function
