Parker Service Master CONNECT User Manual

ENGLISH
6.10.1 CAN X
The CAN X tile displays the following information:
Designation Description
CAN type Current operating mode
Baud rate Current Baud rate
Up to 24 Parker sensors (max. 24channels) can be connected to the
CAN X port. Other setting adjustments are also possible.
6.10.2 CAN Y
The CAN Y tile displays the following information:
Designation Description
CAN type Current operating mode
Baud rate Current Baud rate
The menu is used to select the operating mode and perform further
settings.
The following operating modes are available for selection:
Designation Description
Parker CAN Parker CAN (standard connection)
External CAN External CAN (CANopen)
When Parker CAN operating mode is active, up to 24 Parker sensors
(max. 24channels) can be connected. Sensors with automatic sensor
detection (Parker CAN) are detected by the device and are operational.
Other setting adjustments are not possible.
230
The Parker Service Master CONNECT V1.0/04/20
Operation

Parker Service Master CONNECT Specifications

General

Data Logging	Yes
Connectivity	Bluetooth
Software Compatibility	Parker Service Master Software
Communication Interface	Bluetooth
Power Supply	Rechargeable battery
