110
1 2 3 4 5 6
TP1
v
TP2 TP2
v
TP3 TP3
v
TP4 TP4
v
TP5 TP5
v
TP6 TP6
v
TP7
7 8 9 10 11 12
TP7
v
TP8 TP8
v
TP9 TP9
v
TP10 TP10
v
TP11 TP11
v
TP12 TP12
v
TP13
56_11_574A
TP12 TP10 TP8 TP6 TP4 TP2
TP1TP3TP5TP7TP9TP11
TP13
"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
12 CELL VOLTAGE MEASUREMENT
- Open the battery
- Put on the anti-static bracelet
-Mu
ltimeter
-Anti-static bracelet
Measure the 1st cell
In the example opposite:
-Black test prod on TP1
-Red test prod on TP2
The combination of TP1
v
TP2 gives
us the voltage of the 1st cell of the dia-
gnostic software.
Measurement made with the multimeter
LOCATION OF THE MEASUREMENT POINTS
MEASUREMENT OF THE CELLS, LIST OF COMBINATIONS:
SPECIFIC TOOLS:
USE THE TABLE ON THE PAGE 76 TO VERIFY THE MODEL OF YOUR BATTERY.
ALL BATTERIES (except for Poly 5 and 150 / 150P)
