pellenc 200 - Repair Contacts in the Tool Connector Example: 200 Battery

83
"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
Ź3XVKWKHH[WUDFWRUKDUGZLWKWKHSDOPRI\RXUKDQG
while keeping it aligned with the contact to be extracted
(co
axial with the centerline of the contact concerned).
Feststellung: Signalstiftkontakt im Steckverbinder Batteriegerät 200 gebrochen.
Make the work area safe:in this case, carefully open the battery and remove the fuse.
Extraction of the broken contact: use an ITT CANON extractor, PELLENC P/N 36375.
Ź,QVHUWWKHH[WUDFWRUDURXQGWKHEURNHQFRQWDFWGRZQWRWKHERWWRPRIWKHEDWWHU\FRQQHFWRUVSRWIDFH
Depth of insertion: ~1.5mm.
REPAIR CONTACTS IN THE TOOL CONNECTOR
EXAMPLE: 200 BATTERY
