"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
3- Turn the adjustment screw counter-clockwise to
increase the depth
of the lug to be crimped.
2-
Adjust the mechanical stop so that the contact is
ÀXVKZLWKWKHRSHQLQJ
Contact area
CLOSED BARREL CONTACT
Area to be crimped
1- Insert the contact in the crimping area
P
ALADIN CRIMPING PLIERS PA1461
USING THE PALADIN CRIMPING PLIERS FOR CRIMPING
CLOSED BARREL CONTACTS
