"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
LEVEL 3 - PELLENC AUTHORISED REPAIRER
POSSIBLE CHARGE LEVEL INDICATOR MESSAGES
At the end of level 2 diagnostics, followed by charging, the charge level indicator can indicate
the following possible messages:
Message Meaning Value
E1 Imbalance between 2 cells of more than 100 mV > 100 mV
E2 End-of-charge not detected (stopped by time-out) 8 hours
E3 End-of-charge with voltage error > V
E4 Cell voltage too high > V
E5 Cell voltage too low < V
E6 Current too high on Mos > 7.6 A
OC Detection of cell voltage Over Charge 4.4 V
Messages E1, E2, E3 and OC are faults occurring during the last charging operation.
Messages E4, E5 and E6 are faults occurring during last use.
To cancel the message, operate the switch.
