"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
Tool No.:
Customer’s name:
Date:
Technician’s name:
Customer’s comments:
Fault No.
ÀDVKLQJ
6SHFL¿FWRRO Explanation of the messages displayed
1 Voltage of the weakest cell in mVolts
2 Voltage of the strongest cell in mVolts
3 Start of charging with cell below 2.5 Volts
4 Charger fault
5 Battery continuity fault
6 End of charging with excessive difference between cells
7 Cell not connected, and number concerned
8 Temperature below 0°C during charging
9 Temperature above 60°C during use
10 Temperature above 45°C during charging
11 End of charging with cell above 4.23 Volts
12 Charging stopped with a cell above 4.5 Volts
13 Complete discharge of the battery in use
14 Temp. diff. of more than 10°C between the 2 sensors
15 Balancing resistor fault, and number concerned
16 Tool and battery software version
17 M12 - C21 Excessive current in motor control MOS semiconductors
18 M12 Accelerometer M12 (X & Y)
19 C21 Accelerometer C21 (Y)
20 C21 Excessive temperature on motor MOS semiconductors
21
22
23 M12 - C21 General fault on motor control
24 Power consumption from start-up
25 Number of hours switched on since commissioning
26 Number of hours switched on since last overhaul
BATTERY DIAGNOSTIC WITHOUT SOFTWARE
LEVEL 3 - PELLENC AUTHORISED REPAIRER
