pellenc 200 - Description

17
2
4
10
3
56_10_034A
11 12
13
14
56_07_001B
56_09_013A
1
9
8 7 6 5
"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
1-Battery
2-Carrying
jacket
3-Adjustment buckles
4-Shoulder straps
5-Tool power connector
6-Charging connector
7-Charging connector hatch
8-On/Off switch
9-Battery charge level indicator
10-Pectoral adjustment buckles
11-Charger
12Charging light
13Charger mains power plug
14-Charging connector
DESCRIPTION
LEVEL 2 - USER'S TECHNICAL DEPARTMENT
