pellenc 200 - Li-Ion Diagnostics (All Models)

92
"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
A diagnostic is performed and expressed via a display and an aural beep.
1 – User diagnostic:
Charge indicator message table
NORMAL MESSAGES
IN USE
88 steady Battery charge level (from 0 to 99)
00 1 beep per minute Battery discharged (reserve)
00 ÀDVKLQJZLWKEHHSHYHU\VHFRQGV Stop using, recharge immediately
CHARGING
88 ÀDVKLQJHYHU\VHFRQGV Battery charge level (from 0 to 99)
99 steady Charging complete
STORAGE
88 ÀDVKLQJ Goes into standby after 10 days of non-use
(from 99 to 50 / 150-150P) (from 99 to 45 /
200 - 250) (from 99 to 31 / 400) (from 99 to 15
/ 800) (from 99 to 17 / 700 - Olivion) (from 99
to 20 / 1100) (from 99 to 28 / Poly5)
-- Goes into storage after 13 days of non-use or
voltage too low
MESSAGES IN DEGRADED MODE
IN USE
°C and 55 Alternately The TOOL stops: temperature too high
CHARGING
°C and 00 Alternately Charging interrupted when message displayed
Temp. < or = to 0°C
°C and 45 Alternately Charging interrupted when message displayed
Temp. > or = to 45°C
FAULT MESSAGES
IN USE
88 Beep every 2 minutes for 24 hours Voltage too low after 3 hours of non-use. Re-
charge
battery immediately.
Fixed
Card not valid on test bench, discharge too low
or general fault.
Fixed
The voltage on one cell is too low, or it has a
poor connection to the 12 cells.
CHARGING
Pb and
bA
Alternately, and continuous beep Battery problem
Pb and
CH
Alternately Charger problem
LEVEL 3 - PELLENC AUTHORISED REPAIRER
LI-ION DIAGNOSTICS (ALL MODELS)
