"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
USING THE LI-ION BATTERY SOFTWARE - COMMENTS SCREEN
LEVEL 3 - PELLENC AUTHORISED REPAIRER
Labels Explanations
1 Battery serial number (cannot be changed)
2 Battery software version.
3 Battery internal serial No.
4 Number of battery cells
5 )UHHWH[WLQSXWFRQ¿UPEXWWRQ'RQRWIRUJHWWRFRQ¿UPWKHWH[WEHIRUH\RXH[LW
6
Print button.
7 Return-to-Previous Menu button (comments not saved).
(VF'RQRWIRUJHWWRFRQ¿UPWKHWH[WEHIRUH\RXH[LW
8 Free text entry with save to PC.
9 Free text entry with save to battery memory.
10 Factory settings (cannot be changed).
GREYED-OUT SECTIONS CANNOT BE COMPLETED (FACTORY SETTINGS)
