"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
Item No. Description
1 /
2 /
3 Check current using software’s screen measurement.
4 Check current using software’s screen measurement.
5 Check of charger voltage using the multimeter off load: 50.2 + or – 0.2 Volts.
Use the special adapter to check the voltage.
6 Check of charger voltage using the multimeter off load: 50.2 + or – 0.2 Volts.
Use the special adapter to check the voltage.
7 /
8 /
9 /
10 /
11 /
12 /
USING THE LI-ION BATTERY SOFTWARE - CHARGER SCREEN
LEVEL 3 - PELLENC AUTHORISED REPAIRER
