"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
LEVEL 3 - PELLENC AUTHORISED REPAIRER
INSERTION OF THE FUSE ON THE POLY 5 BATTERY
- Remove the 2 lower right-hand screws of
the battery at the back of the tool using a PZ1
scre
wdriver.
- Put the 40A (58V) fuse in place.
N.B.: Before closing the battery, don’t forget to
replace the strap in position.
- Replace the casing and do up the screws to a
torque of 1Nm
