"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
4. When the soldering iron is at temperature, perform soldering (1 mm < thread Ø < 2 mm)
5. leave the iron on the contact and hold the contact plate with pliers.
CAUTION: press the edge of the contact plate with the pliers to avoid the pliers being trapped in tin when it cools
down!
LEVEL 4 - EXPERT LEVEL
6. Remove the soldering iron and keep the pliers against the plate until the solder has cooled down
7. Solder must cover the entire contact surface.
8. Reinstall the fuse
