"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
LI-ION BATTERY PARAMETERIZATION SOFTWARE INSTRUCTIONS
MANUAL PARAMETERIZATION
If you cannot retrieve the data from the original board mounted on the battery, it is possible to enter the parameters manually.
7KHSDUDPHWHU¿HOGVEHFRPHDFWLYH
You can enter the parameters manually with your PC
Mandatory parameters:
LEVEL 4 - EXPERT LEVEL
Only the existing data of the battery selected will be available.
E.g.: 400 casing blocked on 4 elements in parallel.
• Cell manufacturers: Identify the cell manufacturer using the table on the following page.
• Indicate the number of cells in parallel
Click on the padlock icon to edit the parameters.
