"- LEVEL EXPERT- PELLENC POWER TOOL BATTERY" Workshop document
Issue 11/2016 ref. : DOCUMENT ATELIER_BATTERIE_EXP_OUTILS_PELLENC_V2_2016_ENG
LEVEL 3 - PELLENC AUTHORISED REPAIRER
USING THE LI-ION BATTERY SOFTWARE - MEASUREMENT SCREEN
For the battery values to be consistent, the battery must be charged to at least 20%
Labels Explanations
1
/
2
Voltage values of each cell.
The values that are downloaded are saved.
If correct, the values are displayed in green.
If there is a fault, values are displayed in red: voltage too high or too low.
If in red, validate the reading by means of a hard-wired connection to the board.
3
Charging voltage can be read directly (17 blinks if serial connection)
4
Charging current can be read directly (17 blinks if serial connection)
5
Battery software version.
6
/
7
Battery internal serial No.
8
Number of cells in series, value = 12 S
Number of cells in parallel, value before "P"
1P
= battery 150 / 150P 2 P = battery 200, 250 or Poly 5
4 P = 400 battery
6 P = 700 battery
7 P = 700 / Olivion battery
8 P = 1100 battery
9
/
10
Battery unserviceable if > 100 mV
Battery unserviceable if > 50 mV and "over charge" fault (After checking that there are no faults on the circuit
board)
After a storage period, perform at least 4 full cycles (P22) to ensure reliable information ǻV
11
/
12
/
13
Not usable with infrared.
14
Not usable with infrared.
15
Not usable with infrared.
16
Check there is not a large difference between the two values.
(<10°C difference)
Check for consistency with the ambient temperature.
17
/
18
Active after 2 seconds
19
See page 94 for the battery discharge times table.
20
/
21
/
22
Charge the battery before the diagnosis of battery charge > 20% (capacity
LQVXI¿FLHQWWRFKDUJHEDWWHU\
