21-3．Adjustment screen
When click the adjustment software, the following screen will be displayed
A．Tool bar
B．USB communication display
Display the status of USB open/Close
USB open：Connect
USB closed：Unconnect
Op
USB open: start the communication with camera
（Same as [USB Test] in the menu bar）
Cl
USB close：Close the communication with camera
（same as [USB Test] in the menu bar）
p.s
Print screen（Same function as key board）
ver Display F/W Version
end End of adjustment software
m.n Display menu screen
Connect
76700
A. Tool bar
C. Menu screen
Adjust/Check items
Product number
Menu bar
B. USB communication display
To Next Page
