76700 -59/94-
↓
POSITION CHECK
[AGC LEVEL ADJUST]
[UNIFORMITY ADJUST]
[FOCUS OFFSET ADJUST]
TEMP ADJUSTMENT（ Select . /F . Input temperature . Temp Adjust . Close）
HORIZONTAL・VERTICAL*
（START . Adjust position of chart . STOP . ADJUST . Close）
5：EEPROM CHECKING
When finished all adjustment, click 5：EEPROM CHECKING
* When replaced T100, the following adjustment should be done additionally
6：BATTERY LEVEL ADJUST
Tools: Battery adaptor, Power supply (8V, 3A)
① Follow the screen
When open and close the battery cover, [Pc] will be displayed in the LCD panel of the camera
② Click Op and then start the correspond with camera. Display will change to「- - -」
③ Press BC Adjust and execute the adjustment
④ After finished the adjustment, press Close button
※ If the power turned ON again, execute above ②
7：SHUTTER SPEED ADJUST
Tools: Reflection type of Shutter tester
① Select the shutter tester (1/4000)
② Press RELESE button and release the shutter several times, also measure the data
③ Input Measurements data and press Input Data
④ After finished the adjustment, press Close button
Finish the [5：EEPROM CHECKING] and execute [End procedure]
