37
1
Getting Started
Use of the optional AC adapter kit (K-AC117) is recommended if you intend to use
the camera for a long time or connect it to a computer.
1
Make sure that the camera is turned off and open the battery/
card cover.
2
Remove the Battery.
Refer to p.34 - p.35 on how to open the battery/card cover and remove the
battery.
3
Insert the DC coupler.
Using the side of the DC coupler to press the battery lock lever, insert the DC
coupler. Confirm that the DC coupler is locked in place.
The battery/card cover will not close while the DC coupler is inserted. Leave the
cover open when using the AC adapter and do not attempt to close it.
4
Connect the DC terminal of the AC adapter to the DC terminal
of the DC coupler.
5
Connect the AC plug cord to the AC adapter.
6
Plug the AC plug cord into the power outlet.
Using the AC Adapter
DC terminal
3
1
6
5
DC coupler
4
To Next Page
