59Instructions for Assembly and Use – Standard Configuration
CB 160 Climbing Formwork
C1 Planning and work preparation
Fig. C1.12.1 Fig. C1.12.2
Fig. C1.13.1 Fig. C1.13.2 Fig. C1.13.3
Connecting TRIO formwork
TR 270 x 240 element in an upright
position
The Connector TRIO-CB is to be bolted
to the vertical struts.
(Fig. C1.12.1 – C1.12.3)
The illustrations show girders with a
height of 24 cm.
The Connector TRIO-CB is to be bolted
to the vertical struts.
(Fig. C1.13.1 – C1. 13.3)
35
48.5 2.025
240
30
60
90
120
35
59.5 2.10
270
30
60
90
120
59.5 2.10
3.00
270
270
Fig. C1.12.3
35 35
59.5 2.10
3.00
270
120
30
60
90
120
35
3.226
240
120
30
60
90
120
48.5 2.025
240
240
2.931
48,5 2.025
35
