Instructions for Assembly and Use – Standard Configuration
CB 160 Climbing Formwork
C1 Planning and work preparation
Corner platforms
Corner platforms are to be erected in
such a way that free access is possible
around the corners of the building
when the formwork has either been
shuttered or retracted.
Procedure:
An extended cantilever at a working
platform.
Open edges at the platform ends are to
be secured with end guardrails.
(Fig. C1.19)
In the verification process with the help
of the application diagrams, the girder
cantilever is to be taken into considera-
tion.
Fig. C1.19
Cantilever Bracket spacing
End guardrail
≥ 60
