CB 160 Climbing Formwork
68
Item no. Weight kg
110059 2,840 Waler Fixation U100 – U120
For fixing VARIO GT 24 panels to Strongbacks CB
and SCS, Steel Waler SRU and V-Strongback SKS.
284
8
0
1
2
6
Ø16
80 - 145 76
120
051090 13,500 Connector TRIO-CB
For fixing TRIO panels to the Strongback CB. Used
on horizontal or vertical struts. With integrated
height adjustment.
Complete with
1 pc. 715936 Pin Ø 25 x 180, incl. dowel pin Ø 6
1 pc. 018060 Cotter Pin 4/1, galv.
1
0
0
4
0
0
8
2
1
8
0
Ø25
415
SW 19
051110 24,900 Adjustable Brace CB 164-224
For aligning the Strongback CB.
Complete with
2 pc. 715936 Pin Ø 25 x 180, incl. dowel pin Ø 6
2 pc. 018060 Cotter Pin 4/1, galv.
1580
min 1640 max 2240
8
9
Ø
