Remember...
There are two ways to connect your Cable Box/DBS to the DVD/VCR.With the connection on this page:
● You may watch one channel while recording another. Follow these steps:1) Put the Cable Box/DBS on
the same channel as the DVD/VCR’s CH3/CH4 switch.Set the TV to the Cable Box/DBS output channel
(03 or 04). 2) Press the OUTPUT SELECT button to put the DVD/VCR in VCR mode.Then, press the
VCR/TV button to choose VCR position. 3) Press the CHANNEL o/p buttons to select the channel
you want to record at the DVD/VCR. Start the recording. 4) Press the VCR/TV button once to put the
DVD/VCR in TV position. 5) Select the channel you want to watch at the Cable Box/DBS.
● When you play a tape,make sure the Cable Box/DBS is set to the same channel as the CH3/CH4 switch
on the DVD/VCR.Set the TV to the Cable Box/DBS output channel (03 or 04).
TV’sANTENNA
IN Jack
Cable Box/DBS
DVD/VCR
Connections
1
Connect a Cable signal to the DVD/VCR’s ANT-IN (Antenna In)
Jack.
2
Use an RF coaxial cable (supplied) to connect the ANT-OUT
(Antenna Out) Jack on the DVD/VCR to the IN Jack on the Cable
Box/DBS.
3
Use a second RF coaxial cable to connect the OUT Jack on the
Cable Box/DBS to the ANTENNA IN Jack on the TV.
1
2
3
Cable
Signal
RF coaxial
cable
RF coaxial
cable
DVD/VCR to Cable Box/DBS and TV
Using only basic RF coaxial cables
This connection will let you use the features of both the VCR and the DVD Player.
