Draft - 1 Aug 08
Positioning ECG Electrodes
ECG Monitoring
6-13
3-Wire
Placement
Lead Placement
RA directly below the clavicle and near the
right shoulder
LA directly below the clavicle and near the
left shoulder
LL on the left lower abdomen
RA
LA
LL
