Connecting the ECG Cable
ECG Monitoring
6-21
Connecting the ECG Cable
Caution
Do not insert a leadset in the transceiver during a self-test. The leadset should
be inserted either before the transceiver is powered up, or after the device has
established connection with the Information Center.
Note—When using 3- or 5-wire leadsets, alignment guides should be used to
prevent the build up of debris in open lead ports.
Step
Action
1 Match the arrow on the ECG cable with the arrow on the Lead
Insertion Guide according to the lead type you have chosen, and
insert the ECG cable into the transceiver.
Important—Make sure that the cable is pushed completely into
the transceiver, otherwise the device may not detect the proper
leadset type. When correctly inserted, the colored line at the
base of the cable is not visible.
