Transceiver Controls - Front
3-2 Transceiver Controls
Transceiver Controls - Front
IntelliVue TRx
+
Transceiver - Front View
I 3
I 2
I 1
I 4
B
1
B2
O1
L3
P1
P2
P3
L1
L2
The labeled items in the diagram include:
• Buttons (B1-B2)
• Power On/Off (O1)
• Indicators (I1-I4)
• Labels (L1-L3)
• Ports (P1-P3)
TRx4851A
