Draft - 1 Aug 08
Audible Tones
Transceiver Controls
3-11
Clinical Use
Auditory
Information
Signal Sound How Used
Sound 1 beep Indicates successful Self-Test at power
on.
Indicates successful SpO
2
Spot Check
measurement when measurement is
initiated at the transceiver.
If the Check button is pressed,
confirms that the transceiver is in
contact with the Information Center
(e.g., when transceiver is brought back
into range).
Sound 2 low-pitch tone Indicates pulse detected during Spot Check
SpO
2
measurement.
Note—The pulse tone can be muted from the
Information Center. See “Patient
Configurable Settings in Telemetry Setup” on
page 9-6.
Sound 3 alternating
pitch repeated
tone
Continuous tone to help you locate a missing
transceiver. Initiated by clicking Find
Device in the Telemetry Setup window.
Tone continues until Check button is pressed,
batteries are removed, or batteries completely
discharge.
