Battery Information
Basic Operation
4-17
Checking
the Battery
Power Level
When the Check button is pressed, the battery gauge on the transceiver indicates
the battery power level. It is reliable only when specified batteries (i.e., AA 1.5V
Alkaline) are used. The battery gauge is also displayed in the Patient Sector at
the Information Center (if configured) to enable you to closely monitor battery
status, for example, after a change of shift.
To check the power level of the transceiver:
Step Action
1 If connected, disconnect the transceiver from Telemon or MP5.
1Press the
Check button to determine the level (see Battery Levels
following).
2 If no indicators flash:
1. Check that the batteries are inserted properly.
2. Replace both batteries.
3. If there are still no indicators on the battery gauge, contact
your service provider.
If the indicators illuminate but do not behave as described above,
the transceiver has malfunctioned. Contact your service provider.
