Connecting the ECG Cable
6-22 ECG Monitoring
2 3-wire
Step
Action
Match the arrow on the cable
with the left arrow (labeled
EASI, 3) on the Leadset In-
sertion Guide.
Note—Leadset is keyed for
only one insertion position.
EASI, 3
5.6
IntelliVue TRx
M4841A
colored
line
