Connecting the ECG Cable
ECG Monitoring
6-23
3 5-wire Standard
5-wire EASI
Note—If you are using a 5-wire leadset in both Standard and EASI
modes, insert the alignment guide into the open lead port with the
wide lip facing the leads. Then, press down firmly so that the guide
is securely under the leadset and the colored line is not visible.
Step
Action
Match the arrow on the cable
with the right arrow (labeled 5,
6) on the Leadset Insertion
Guide.
EASI, 3
5.6
IntelliVue TRx
M4841A
li ne
colored
line
Match the arrow on the cable
with the left arrow (labeled
EASI, 3) on the Leadset In-
sertion Guide.
EASI, 3
5.6
IntelliVue TRx
M4841A
colored
line
