Positioning ECG Electrodes

ECG Monitoring

6-15

V1 on the fourth intercostal space at the right

sternal border

V2 on the fourth intercostal space at the left

sternal border

V3 midway between the V2 and V4 electrode

positions

V4 on the fifth intercostal space at the left

midclavicular line

V5 on the left anterior axillary line, horizontal

with the V4 electrode position

V6 on the left midaxillary line, horizontal

with the V4 electrode position

Lead Placement
