Positioning ECG Electrodes
6-18 ECG Monitoring
LA directly below the clavicle and near the
left shoulder
RL on the right lower abdomen
LL on the left lower abdomen
Va on the chest, the position depends on
your required lead selection (see
below). The default position is V2. For
other positions, relabel the lead at the
Information Center.
Vb on the chest, the position depends on
your required lead selection (see
below). The default position is V5. For
other positions, relabel the lead at the
Information Center.
