Pioneer MEP-7000 Service Manual

141
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
(1) SLOT-IN MECHA SECTION PARTS LIST
Mark No. Description Part No.
NSP 1 Slot-in Mechanism Assy DXA2123
2Traverse Assy 03-S VXX3125
3 Loading Motor Assy-S DXX2510
NSP 4 Worm Gear DNK3910
NSP 5 DC Motor S (ROHS) DXM1230
6 • • • • •
7 Clamp Spring DBH1374
8Guide Spring DBH1375
9SW Lever Spacer SV DEC2831
10 Loading Gear Assy DXB1880
11 Main Cam DNK3407
12 Disc Guide DNK3478
13 Clamp Arm DNK3576
14 Eject Lever DNK3684
15 Lever AP DNK3835
16 Lever BP DNK3836
17 Loading Gear DNK3911
18 Drive Gear DNK3912
19 Loading Base SV DNK4369
20 SW Lever SV1 DNK4370
21 SW Lever SV2 DNK4371
22 Gear Holder SV DNK4372
23 Clamper 04 Assy DXX2591
24 Screw BPZ20P060FTC
25 Float Rubber (SI) VEB1351
26 Float Base 04 Assy DXB1838
27 Spacer (T3) DEB1566
28 Vessel Cushion A DEC2852
29 Vessel Cushion B DEC2853
30 Vessel Cushion C DEC2854
31 Front Sheet DED1132

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
