Pioneer MEP-7000 Service Manual

281
MEP-7000
5
6 7 8
5
6 7 8
A
B
C
D
E
F
CN 401 CONNECTOR AKM1294
CN 500 CONNECTOR AKM1293
CN 501 CONNECTOR AKM1289
>
P 101 PROTECTOR(1.000A) DEK1097
>
P 102 PROTECTOR(1.750A) DEK1100
>
P 103-106 PROTECTOR(1.250A) DEK1098
RESISTORS
R 247,251,255 RAB4CQ100J
R 252,266,381,385 RS1/16S0R0J
R 260,399,522 RS1/16SS3302F
R 261,1300 RS1/16SS5602F
R 267-270 RAB4CQ100J
R 278-281,284,288 RAB4CQ470J
R 282,294,295,300 RAB4CQ220J
R 290,293,296-298 RAB4CQ470J
R 301,319,323,1205 RAB4CQ220J
R 302,303,407,408 RAB4CQ470J
R 386,545-550,1583 RS1/16S0R0J
R 388,391,395,396 RS1/16S220J
R 390,392-394 RS1/16S331J
R 410,412-415,1204 RAB4CQ470J
R 442 RS1/16SS1202F
R 521 RS1/16SS2202F
R 535 RAB4CQ103J
R 1301,1303,1314-1324 RS1/16S220J
R 1310-1313,1325-1328 RAB4C220J
R 1329-1339 RS1/16S220J
R 1380,1592 RS1/4SA0R0J
R 1587,1593,1595 RS1/16S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 200,207-211 CKSSYB104K10
C 201,205 CCSSCH8R0D50
C 202,300-307,310 CKSSYB103K16
C 213-226,228-233 CKSSYB104K10
C 227,253-256 BCG1054
C 234,334 CEVW101M6R3
C 235-252,257,309 CKSSYB104K10
C 311,313-323,326 CKSSYB103K16
C 324,327,329,332 CKSSYB104K10
C 325,372,374 DCH1201
C 330,386-388 CCSRCH102J50
C 333,427,528,1400 CKSSYB103K16
C 335,336,351-354 CKSSYB104K10
C 337-339,367-369 BCG1054
C 356-358,375,376 CKSSYB104K10
C 359,1405,1406 CEHVW101M6R3
C 360,390,551,554 CEVW101M16
C 361-366,535-540 CKSRYB104K16
C 371,378,415,421 BCG1054
C 379,402-414,416 CKSSYB104K10
C 391-399 CCSSCH471J16
C 400,401 CCSSCH9R0D50
C 418-420,422,425 CKSSYB104K10
C 423,424,429 BCG1054
C 426,428,431-434 CKSSYB104K10
C 435,436,541-544 CEVW470M16
C 502,505-507 CKSSYB104K10
Mark No. Description Part No.
C 512-519,521-523 CKSSYB104K10
C 520,529,530 CEVW101M10
C 524,525 CCSSCH180J50
C 526,527,552,553 CKSSYB104K10
C 531,532,567,1404 CEVW470M6R3
C 549,550 CKSRYB104K16
C 565,566,1401,1402 CKSSYB104K10
C 701-710 CCSSCH101J50
C 711-720 CKSSYB102K50
C 1391-1399 CCSRCH221J50
C 1403 CEVW101M16
B
EJTB ASSY
SEMICONDUCTORS
Q 4200,4201 RT1N241M
D 4200-4202 SLI-343P8C(ABCD)
MISCELLANEOUS
S 4200,4201 SWITCH VSG1024
CN 4200 PLUG(10P) KM200NA10LE
CN 4201 CONNECTOR SLW6R-1C7
RESISTORS
All Resistors RS1/16S###J
C
FSWB ASSY
SEMICONDUCTORS
Q 4100,4101 RT1N241M
D 4100,4101 SLI-343U8RC(HJKL)
MISCELLANEOUS
S 4100,4101 SWITCH VSG1024
CN 4100 CONNECTOR SLW6R-1C7
RESISTORS
All Resistors RS1/16S###J
D
SJACK ASSY
SEMICONDUCTORS
IC 10,11 NJM4580D
>
IC 12 NJM7815FA
>
IC 13 NJM7915FA
Q 10,12 RT1P241M
Q 11,13 RT1N241M
Q 14-21 2SD2114K
>
Q 24 2SD2114K(VW)
D 12-15,20 HZM6R2ZMWA
D 16-19 1SS352
D 21 UDZS12(B)
MISCELLANEOUS
L 10,11 CHIP SOLID INDUCTOR XTL3010
L 12,13 FERRITE CORE VTF1090
JA 10,11 JACK VKB1243
JA 12 2P PIN JACK DKB1085
JA 13 10P MIN DIN SOCKET DKP3788
JA 14 PIN JACK(4P) DKB1090
JA 15 USB CONNECTOR BKP1164
JA 16 USB CONNECTOR DKN1237
KN 10,11 WRAPPING TERMINAL VNF1084
Mark No. Description Part No.

Pioneer MEP-7000 Specifications

General

Frequency range	4 - 20000 Hz
Channels quantity	- channels
Digital sound processing	- bit
Total Harmonic Distortion (THD)	0.006 %
Dimensions (WxDxH)	483 x 325 x 91 mm
Power consumption (typical)	33 W

Weight and Dimensions

Weight	6100 g
