Piper TURBO ARROW III User Manual

TABLE IV-II
MAXIMUM DISTANCE BETWEEN SUPPORTS FOR FLUID TUBING
TUBE OD DISTANCE BETWEEN SUPPORTS (IN.)
(IN.) ALUMINUM ALLOY STEEL
1/8 9-1/2 11-1/2
3/16 12 14
1/4 13-1/2 16
5/16 15 18
3/8 16-1/2 20
1/2 19 23
5/8 22 25-1/2
3/4 24 27-1/2
1 26-1/2 30
TABLE IV-III. Hose clamp tightening,
(initial installation).
Types of clamps
Types of hose
Worm screw type All other types
Self sealing Finger-tight-plus Finger-tight-plus
2 complete turns 2 1/2 complete turns
All other hose Finger-tight-plus Finger-tight-plus
1 1/4 complete turns 2 complete turns
lf clamps do not seal at specified tightening, examine hose connection and replace parts as necessary.
Added: 5/1/80
1F2
* CHEROKEE ARROW III SERVICE MANUAL
STRUCTURES

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
