Revised: 2/13/89
2G11
CHEROKEE ARROW III SERVICE MANUAL
INSTRUMENTS
10-66. TROUBLESHOOTING.
TABLE X-XIII. FUEL QUANTITY INDICATORS
Trouble Cause Remedy
Fuel gauge fails to indicate. Broken wiring. Check and repair
Gauge not operating. Replace.
Fuel gauge indicates empty Incomplete ground. Check ground connections at
when tanks are full. fuel transmitter in wings.
Fuel gauge indicates full Incomplete ground. Check ground at instrument.
with tanks empty.
Float arm stuck. Replace fuel transmitter.
Fuel gauge indicated Intermittent electrical Check ground at grounded
incorrectly. connection. transmitter and electrical
connections.
Float arm sticky. Replace fuel transmitter.
Insulated transmitter Remove transmitter and
grounded. sealant. Check for metal
particles in sealant. Reseal
to prevent ground.
10-67. REMOVAL AND REPLACEMENT. (Refer to Paragraph 10-78 of this section.)
10-68. OIL TEMPERATURE INDICATOR.
10-69. GENERAL. The oil temperature indicator is mounted in the instrument cluster on the instrument panel.
This instrument will provide a temperature indication of the engine oil in degrees Fahrenheit. The instrument
has a temperature bulb located in the oil screen assembly on engines with screens, and on the top of the oil
cooler mounting flange on engines with an oil filter, located on the engine accessory section.
