TABLE II-III. RECOMMENDED ENGINE LUBRICATING OILS
PA-28R-201
Average Average Ambient Oil Inlet Temperatures
Grade Oil Air Temperature Desired Maximum
SAE 50 Above 60°F 180°F 245°F
(16°C) (82°C) (118°C)
SAE 40 30°F to 90°F 180°F 245°F
(-1°C to 32°C) (82°C) (118°C)
SAE 30 0°F to 70°F 170°F 225°F
(-17°C to 20°C) (77°C) (107°C)
SAE 20 Below 10°F 160° F 210°F
(12°C) (71°C) (99°C)
PA-28R-201T
Average Average Ambient
Grade Oil Air Temperature
SAE 50 Above 40°F
SAE 30 or Below 40°F
10-W-30
NOTE
When the average ambient air temperature is approximately at the dividing
line, use the lighter oil.
Revised: 8/31/77
1C2
*CHEROKEE ARROW III SERVICE MANUAL
HANDLING AND SERVICING

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
