Figure 8-4. Propeller Blade Minor Repair
TABLE VIII-I. PROPELLER SPECIFICATIONS
Blade Angle
(l)
Low Pitch (High RPM) 14.4° ± 0.2°
High Pitch (Low RPM) 29° ± 1.0°
Propeller RPM Setting Engine Static High RPM 2575 RPM max.
Propeller Torque Limits Description Required Torque (Dry)
Spinner Bulkhead (Aft) 20-22 foot-pounds
Propeller Mounting 60-70 foot-pounds
Spinner Attachment Screws 35-40 inch-pounds
(1) MEASURED AT 30 INCH STATION.
Revised: 8/31/77
2A16
CHEROKEE ARROW III SERVICE MANUAL
POWER PLANT - CONTINENTAL

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
