Piper TURBO ARROW III User Manual

TABLE XIV-I. TEMPERATURE PRESSURE CHART
Evaporator Pressure Evaporator High Pressure Ambient
Gauge Reading Temperature Gauge Reading Temperature
psi °F. psi °F.
0 -21 72 40
2.4 -15 86 50
4.5 -10 105 60
10.1 2 109 62
11.2 4 113 64
12.3 6 117 66
13.4 8 122 68
14.6 10 126 70
15.8 12 129 71
17.1 14 132 72
18.3 16 134 73
19.7 18 137 74
21 20 140 75
22.4 22 144 76
23.1 23 148 77
23.8 24 152 78
24.6 25 156 79
25.3 26 160 80
26.1 27 162 81
26.8 28 165 82
27.6 29 167 83
28.4 30 170 84
29.2 31 172 85
30 32 175 86
30.9 33 177 87
31.7 34 180 88
32.5 35 182 89
33.4 36 185 90
34.3 37 187 91
35.1 38 189 92
36 39 191 93
36.9 40 193 94
37.9 41 195 95
38.8 42 200 96
39.7 43 205 97
41.7 45 210 98
43.6 47 215 99
45.6 49 220 100
48.7 52 228 102
49.8 53 236 104
55.4 57 260 110
60 62 275 115
64.9 66 290 120
Revised: 2/13/89
3A9
CHEROKEE ARROW III SERVICE MANUAL
ACCESSORIES AND UTILITIES

Piper TURBO ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	Turbo Arrow III
Horsepower	200 hp
Max Takeoff Weight	2, 900 lbs
Fuel Capacity	72 gallons
Service Ceiling	20, 000 ft
Seating Capacity	4
Type	Single-engine piston
Propeller	Constant-speed
Landing Distance	1, 200 ft
