TABLE VII-II. TROUBLESHOOTING CHART (LANDING GEAR)
Red gear unsafe light out Indicator lamp burned Replace lamp.
while gear is in transit. out.
Indicator light ground Check ground circuit.
incomplete.
Indicator light circuit Check wiring.
wire broken.
Indicator light circuit Reset circuit breaker
breaker open. and determine cause
for open circuit
breaker.
Red gear unsafe light One or more up limit Isolate and replace
on though gear has switches failed. switch.
retracted.
Nose gear up limit Check gear up adjustment
switch out of ad- and readjust up limit
justment. switch.
Main gear not Check gear up
retracting far adjustment.
enough to actuate
switch.
Red gear unsafe light One or more down Isolate and replace
on though gear is limit switches failed. switch.
down and locked.
Nose gear down limit Readjust down limit
switch our of adjustment. switch.
Main gear down limit Readjust down limit
switch out of adjustment. switch.
NOTE
The out of adjustment or failed switch may be determined by noting which
down light is not lit.
Trouble Cause Remedy
Revised: 2/13/89
CHEROKEE ARROW III SERVICE MANUAL
HYDRAULIC SYSTEM
